Product Summary
The X5045PI is a CPU Supervisor with 4Kbit SPI EEPROM. It combines four popular functions, Poweron Reset Control, Watchdog Timer, Supply Voltage Supervision, and Block Lock Protect Serial EEPROM Memory in one package. This combination lowers system cost, reduces board space requirements, and increases reliability. Applying power to the X5045PI activates the power-on reset circuit which holds RESET/RESET active for a period of time. This allows the power supply and oscillator to stabilize before the processor can execute code.
Parametrics
X5045PI absolute maximum ratings: (1)Temperature under bias: -65℃ to +135℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on any pin with respect to VSS: -1.0V to +7V; (4)D.C. output current: 5mA; (5)Lead temperature (soldering, 10 seconds): 300℃.
Features
X5045PI features: (1)Low VCC Detection and Reset Assertion; (2)Selectable Time Out Watchdog Timer; (3)Long Battery Life with Low Power Consumption; (4)4Kbits of EEPROM-1M Write Cycle Endurance; (5)Built-in Inadvertent Write Protection; (6)SPI Interface - 3.3MHz Clock Rate; (7)Minimize Programming Time; (8)Pb-Free Plus Anneal Available (RoHS Compliant).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 X5045PI |
|
IC CPU SUPRV 4K EE RST HI 8DIP |
Data Sheet |
Negotiable |
|
||||||
|
X5045PI-2.7 |
|
IC CPU SUPRV 4K EE RST HI 8DIP |
Data Sheet |
Negotiable |
|
||||||
|
X5045PI-4.5A |
|
IC CPU SUPRV 4K EE RST HI 8DIP |
Data Sheet |
Negotiable |
|
||||||
|
X5045PI-2.7A |
|
IC CPU SUPRV 4K EE RST HI 8DIP |
Data Sheet |
Negotiable |
|
||||||
|
X5045PIZ |
|
IC SUPERVISOR CPU 4K EE 8-DIP |
Data Sheet |
|
|
||||||
|
X5045PIZ-2.7 |
|
IC SUPERVISOR CPU 4K EE 8-DIP |
Data Sheet |
|
|
||||||
|
X5045PIZ-2.7A |
|
IC SUPERVISOR CPU 4K EE 8-DIP |
Data Sheet |
|
|
||||||
|
X5045PIZ-4.5A |
|
IC SUPERVISOR CPU 4K EE 8-DIP |
Data Sheet |
|
|
||||||
