Product Summary

The UA78L05ACDR is a fixed-voltage integrated-circuit voltage regulator which is designed for a wide range of applications. These applications include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, UA78L05ACDR can be used with power-pass elements to make high-current voltage regulator. UA78L05ACDR can deliver up to 100 mA of output current.

Parametrics

UA78L05ACDR absolute maixmum ratings: (1)Input voltage, VI: 30 V; (2)Virtual junction temperature, TJ: 150℃; (3)Storage temperature range, Tstg: -65℃ to 150℃.

Features

UA78L05ACDR features: (1)3-Terminal Regulators; (2)Output Current Up To 100 mA; (3)No External Components; (4)Internal Thermal-Overload Protection; (5)Internal Short-Circuit Current Limiting.

Diagrams

UA78L05ACDR schematic

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
UA78L05ACDR
UA78L05ACDR

Texas Instruments

Linear Regulators - Standard 5.0V 100mA

Data Sheet

0-1: $0.24
1-25: $0.16
25-100: $0.13
100-250: $0.11
UA78L05ACDRE4
UA78L05ACDRE4

Texas Instruments

Linear Regulators - Standard 5V 100mA Fixed Pos Voltage Regulator

Data Sheet

0-1: $0.31
1-25: $0.22
25-100: $0.19
100-250: $0.16
UA78L05ACDRG4
UA78L05ACDRG4

Texas Instruments

Linear Regulators - Standard 5V 100mA Fixed Pos Voltage Regulator

Data Sheet

0-1: $0.26
1-25: $0.21
25-100: $0.18
100-250: $0.16
