Product Summary

The SN74HC74PWR is a dual d-type positive-edge-triggered flip-flop. A low level at the preset (PRE) or clear (CLR) inputs sets or resets the outputs, regardless of the levels of the other inputs. When PRE and CLR are inactive (high), data of the SN74HC74PWR at the data (D) input meeting the setup time requirements are transferred to the outputs on the positive-going edge of the clock (CLK) pulse. Clock triggering occurs at a voltage level and is not directly related to the rise time of CLK. Following the hold-time interval, data of the SN74HC74PWR at the D input can be changed without affecting the levels at the outputs.

Parametrics

SN74HC74PWR absolute maximum ratings: (1)Supply voltage range:–0.5 V to 7 V; (2)Input clamp current, IIK (VI < 0 or VI > VCC):±20 mA; (3)Output clamp current, IOK (VO < 0 or VO > VCC):±20 mA; (4)Continuous output current, IO (VO = 0 to VCC):±25 mA; (5)Continuous current through VCC or GND:±50 mA; (6)Package thermal impedance, θJA:86℃/W; (7)Storage temperature range:–65℃ to 150℃.

Features

SN74HC74PWR features: (1)Wide Operating Voltage Range of 2 V to 6 V; (2)Outputs Can Drive Up To 10 LSTTL Loads; (3)Low Power Consumption, 40-μA Max ICC; (4)Typical tpd = 15 ns; (5)±4-mA Output Drive at 5 V; (6)Low Input Current of 1 μA Max.

Diagrams

SN74HC74PWR pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SN74HC74PWR
SN74HC74PWR

Texas Instruments

Flip Flops Dual w/Clear Preset

Data Sheet

0-1: $0.20
1-25: $0.16
25-100: $0.12
100-250: $0.08
SN74HC74PWRE4
SN74HC74PWRE4

Texas Instruments

Flip Flops Dual Pos-Edge-Trig D-Type Flip-Flop

Data Sheet

0-1: $0.23
1-25: $0.16
25-100: $0.12
100-250: $0.09
SN74HC74PWRG4
SN74HC74PWRG4

Texas Instruments

Flip Flops Dual Pos-Edge-Trig D-Type Flip-Flop

Data Sheet

0-1: $0.23
1-25: $0.16
25-100: $0.12
100-250: $0.09
