Product Summary

The PMBT2222A is an NPN switching transistor. It is available in a SOT23 plastic package. The applications of PMBT2222A include Switching and linear amplification.

Parametrics

PMBT2222A absolute maximum ratings: (1)collector-base voltage:75 V; (2)collector-emitter voltage:40 V; (3)emitter-base voltage:6 V; (4)collector current (DC):600 mA; (5)peak collector current:800 mA; (6)peak base current:200 mA; (7)total power dissipation:250 mW; (8)storage temperature:-65℃ to +150℃; (9)junction temperature:150℃; (10)operating ambient temperature:-65℃ to +150℃.

Features

PMBT2222A features: (1)High current (max. 600 mA); (2)Low voltage (max. 40 V).

Diagrams

PMBT2222A top view

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
PMBT2222A
PMBT2222A

Other


Data Sheet

Negotiable
PMBT2222A /T3
PMBT2222A /T3

NXP Semiconductors

Transistors Bipolar (BJT) TRANS SW TAPE-11

Data Sheet

Negotiable
PMBT2222A,215
PMBT2222A,215

NXP Semiconductors

Transistors Bipolar (BJT) NPN SW 600MA 40V

Data Sheet

0-1: $0.03
1-25: $0.01
25-100: $0.01
100-250: $0.01
PMBT2222A,235
PMBT2222A,235

NXP Semiconductors

Transistors Bipolar (BJT) TRANS SW TAPE-11

Data Sheet

0-1: $0.03
1-25: $0.03
25-100: $0.02
100-250: $0.02
