IRF3415STRRPBF

HEXFET power MOSFET, 150V, 43A, D2PAK, 0.042Ω, Advanced process technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~1.00

PartNumber:: IRF3415STRRPBF

Brand:: International Rectifier - IR | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. jacker's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-27

From Other Seller

Part Number:IRF3415STRRPBF
US $0.10 - 1.00
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRF3415STRRPBF is a HEXFET power MOSFET. It uses advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that the IRF3415STRRPBF is well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications. The IRF3415STRRPBF is suitable for high current applications because of its low internal connection resistance and can dissipate up to 2.0W in a typical surface mount application.

Parametrics

IRF3415STRRPBF absolute maximum ratings: (1)ID @ Tc=25℃ Continuous drain current, VGS @ 10V: 43A; (2)ID @ Tc=100℃ Continuous drain current, VGS @ 10V: 30A; (3)IDM Pulsed drain current: 150A; (4)PD @ TA=25℃ Power dissipation: 3.8W; (5)PD @ TC=25℃ Power dissipation: 200W; (6)Linear derating factor: 1.3W/℃; (7)VGS Gate-to-source voltage: ±20V; (8)EAS Single pulse avalanche energy: 590mJ; (9)IAR Avalanche current: 22A; (10)EAR Repetitive avalanche energy: 20mJ; (11)dv/dt Peak diode recovery dv/dt: 5.0V/ns; (12)TJ TSTG operating junction and Storage temperature range: -55 to +175℃; (13)Soldering temperature, for 10 seconds: 300(1.6mm from case).

Features

IRF3415STRRPBF features: (1)Advanced process technology; (2)Surface mount; (3)175℃ operating temperature; (4)Fast switcing; (5)Fully avalanche rated; (6)Lead-free.
