Product Summary

The 2N7002 is an N-Channel 60-V (D-S) MOSFET. Applications include: (1)Direct Logic-Level Interface: TTL/CMOS; (2)Drivers: Relays, Solenoids, Lamps, Hammers, Displays, Memories, Transistors, etc.; (3)Battery Operated Systems; (4)Solid-State Relays.

Parametrics

2N7002 absolute maximum ratings: (1)Drain-Source Voltage VDS 60V; (2)Gate-Source Voltage—Non-Repetitive VGSM: ±40V; (3)Gate-Source Voltage-Continuous VGS: ±20V; (4)Continuous Drain Current TA= 25℃: 0.115V; TA= 100℃, ID: 0.073A; (5)Pulsed Drain Current IDM: 0.8A; (6)Power Dissipation: TA= 25℃: 0.2W; TA= 100℃: 0.08W; (7)Thermal Resistance, Junction-to-Ambient RthJA: 625℃/W; (8)Operating Junction and Storage Temperature Range TJ, Tstg: –55 to 150℃.

Features

2N7002 features: (1)Low On-Resistance: 2.5Ω; (2)Low Threshold: 2.1 V; (3)Low Input Capacitance: 22 pF; (4)Fast Switching Speed: 7 ns; (5)Low Input and Output Leakage.

Diagrams

2N7002 diagram
