UC3843BD1TR-2LF

current mode PWM controller, SOP8, 30 V, ±1 A, low start-up, 500khz, STMicroelectronics

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~1.00

PartNumber:: UC3843BD1TR-2LF

Brand:: STMicroelectronics - ST | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. jacker's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-26

From Other Seller

Part Number:UC3843BD1TR-2LF
US $0.10 - 1.00
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The UC3843BD1TR-2LF is a high performance current mode PWM controller. It provides the necessary features to implement off-line or DC to DC fixed frequency current mode control schemes with a minimal external parts count. Internally implemented circuits of the UC3843BD1TR-2LF include a trimmed oscillator for precise DUTY CYCLE CONTROL under voltage lock out featuring start-up current less than 0.5mA, a precision reference trimmed for accuracy at the error amp input, logic to insure latched operation, the UC3843BD1TR-2LF also provides current limit control, and a totem pole output stage designed to source or sink high peakcurrent.

Parametrics

UC3843BD1TR-2LF absolute maximum ratings: (1)Vi Supply Voltage (low impedance source): 30 V; (2)IO Output Current: ±1 A; (3)EO Output Energy (capacitive load): 5 mJ; (4)Analog Inputs (pins 2, 3): -0.3 to 5.5 V; (5)Error Amplifier Output Sink Current: 10 mA; (6)Ptot Power Dissipation at Tamb ≤ 25 ℃ (Minidip) 1.25 W; (7)Ptot Power Dissipation at Tamb ≤ 25 ℃ (SO8): 800 mW; (8)Tstg Storage Temperature Range: -65 to 150 ℃; (9)TJ Junction Operating Temperature: -40 to 150 ℃; (10)TL Lead Temperature (soldering 10s): 300 ℃.

Features

UC3843BD1TR-2LF features: (1)trimmed oscillator for precise frequency control; (2)oscillator frequency guaranteed at 250khz; (3)current mode operation to 500khz; (4)automatic feed forward compensation; (5)latching pwm for cycle-by-cycle current limiting; (6)internally trimmed reference with undervoltage lockout; (7)high current totem pole output; (8)undervoltage lockout with hysteresis; (9)low start-up and operating current.
